360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine

Product Categories
Quanzhou Deli Agroforestrial Machinery Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine

Condition : New

Applicable Industries : Farms

Showroom Location : None

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Marketing Type : Hot Product 2019

Warranty of core components : 1 Year

Core Components : Engine

Brand Name : DELI ASSISTANT

Place of Origin : China

Voltage : 220v/380

Power : 13.5kw

Dimension(L*W*H) : 710*680*1350

Weight : 360 KG

Warranty : 1 Year

Application fields : tea leave

Raw material : tea leave

Output product name : tea leave

Heating type : Electric heating

Heating power Pallet : 12 kw

rotary speed : 6 rpm

Pallet layer : 12 layers

Drying area : 6.4 m2

Price : $1,614.00/sets 1-4 sets

Contact Now

360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine
360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine

Tea Garden Management Equipments

360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine

Tea Withering Machine

360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine

Tea leaf fixation machine

360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine

Tea Rolling Machine

360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine

Tea Fermentation Machine

360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine

Tea Dryer Machine

these machine is part of the tea planting and production, If you want to know more information about these machines, or there is no machine you need here.please contact us.
360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine

Tea drying machine description

For non-fermented tea such as green tea: evaporate water, tighten the tea, make the tea fully dry, divergent to remove the grassy taste, enhance the aroma of the tea.

For fermented tea such as black tea: the activity of the enzyme is destroyed by high temperature, the enzymatic oxidation is interrupted, and the quality of the tea is maintained.
Evaporate the water in the tea leaves, so that the tea leaves are fully dried, divergent to remove the grassy taste, and enhance the aroma of the tea leaves.

For herbal tea: Evaporate water, tighten flowers and plants, and keep the original color and original aroma

Tea drying machine usage

Tea drying machine can process almost all tea: such as black tea, green tea, oolong tea, and herbal tea.

360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine
Model
DL-CHZ-9B
Dimension
1420*1100*2190mm
Voltage
220v/380V
Heating type
Electric heating wire
Heating power
13.5kw
Pallet rotary speed
6rpm
Drying area
10.1m2
Pallet layers
16layers
Efficiency
27kg/batcch

The above data is based on fresh tea leaf water content of 30-40%

Model
6CHZ-2
6CHZ-5
6CHZ-9
6CHZ-14
6CHZ-34
Trays Quantity
10 pcs
14 pcs
16 pcs
16 pcs
36 pcs
Trays Diameter
50 cm
70 cm
90 cm
110 cm
110 cm
Drying Area
2 m2
5 m2
9 m2
14 m2
34 m2
Capacity
6-8 kg
15-20 kg
27-36 kg
42-56 kg
102-136 kg
360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine

Intelligent temperature and time control system

Microcomputer temperature controller is adopted, keep the temperature difference below 1℃.


Add mechanical temperature limiting module to ensure precise temperature control.


The drying time is adjustable, alarm will be made at the end of drying ( can manually choose to turn on or off ).


360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine

Patent duct design

The design of the wind tunnel has got the national patent, which makes the heat more uniform, the drying is more efficient and the noise is lower.

360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine

Copper core motor

Copper core motor is used to ensure smooth operation of the machine, ensure heat transfer and moisture vapor emission.

360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine

Heat-insulation system

The metal plate inside the machine is coated with special coating, which reflects the heat inside the machine. The heat loss is small and the drying speed is faster.

360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine

Tea drying machine modular design

The whole tea drying equipment adopts modular design, and after-sales service is more convenient.

360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine

Rotary drying method for tea

Tea drying machine using rotary drying design, the tea is heated more evenly and has better quality.

360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine
360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine
360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine
360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine
360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine
360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine

If you are interested in tea drying machine, please click here to send us enquiries.

360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine
Obtain ISO9001 quality system certification
More than 30 Chinese honorary certificates
More than 20 Chinese national patent certificates
More than 50 promotion certificates of China Agriculture Ministry
360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine
360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine
360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine
360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine
Customers visit our factories
360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine
360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine
360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine
Part of the our workshop photos
360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine
360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine
360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine
360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine
360 KG DL-6CHZ-9B Tea Processing Methods Tea Machine Factories Small Tea Drying Machine
get more information please contact
